Cutting Panel Saw is a powerful, heavy-duty saw ideal for all your woodworking projects. It has a power rating of 5.5KW + 1.1KW, weighs 800kg, and has a package size of 1000*600*800mm. This table saw comes with a dust extraction port and can be tilted up to an angle of 45°. Cutting Panel Sawmakes cutting, ripping, and crosscutting wood easier and faster. Cutting Panel Saw It is perfect for professional and amateur woodworking projects. The sliding table saw is designed to handle the toughest material and guarantees precision and accuracy with every cut. Cutting Panel SawWith its high-end features, this table saw can help you achieve your woodworking goals in no time
Applications
Woodworking Sliding Table Saw
This Woodworking Sliding Table Saw is the perfect saw for professionals and DIYers alike. It is made with a high-quality design and superior components. The power of the motor is 5.5KW + 1.1KW and blade speed is 8000rpm, suitable for a wide range of projects. The table saw has a durable construction and is built to last, with a weight of 800kg. It is easy to use and install. This Woodworking Sliding Table Saw is capable of making accurate cuts with precision and ease. It comes with a 1-year warranty and CE certification.
The Woodworking Sliding Table Saw is an ideal choice for woodworking projects. It is made by OSETMAC and has a model number MJ6132BD. This saw is available for minimum order quantity of 1, and the price is 2800. The packaging is done in a wooden box and the payment terms are FOB and T/T. The company offers a supply ability of 10000 PCS/YEAR.
Specification
|
Sliding Table Dimension |
3200*390mm |
|
Cast Iron Table Dimension |
910*620*80mm |
|
length extension table |
905*680*70mm |
|
width cutting extension table |
640*680*70mm |
|
Main Saw Diameter |
300mm |
|
Main Saw Blade Diameter Maximum |
350mm |
|
Main Saw Bore Diameter |
30mm |
|
Max. Cutting Height With Bade at 90 |
80/100mm(φ300/350) |
|
Max. Cutting Height With Bade at 45 |
50/70mm(φ300/350) |
|
Main Motor Power |
5.5KW |
|
Main Blade Speed |
4000/6000RPM |
|
Scorning Saw Blade Diameter |
120mm |
|
Scorning Saw Bore Diameter |
20mm |
|
Scorning Saw Motor Power |
1.1KW |
|
Scorning Blade Speed |
8000RPM |
|
Max. Cutting Width |
1250mm |
|
Max. Cutting Length |
3100mm |
|
Blade Tilting Adjustment |
0-45° |
|
Main Saw Height Adjustment |
Electric |
|
Scorning Saw Height Adjustment |
Manual |
|
Dust Guard Outlet Diameter |
80mm |
|
Dust System Outlet Diameter |
100mm |
|
Dimension of Wood Packing Carton |
2250*1200*1100mm(Main Crate ) |
|
3400*450*290mm(Sliding Table) |
|
|
Dimension |
3250*3450*900mm |
|
G. W. |
800KG |
