Planer and Spindle Moulder

Your Leading Planer and Spindle Moulder Supplier

Qingdao Oset International Trading Co., Ltd. is a professional woodworking machinery manufacturer. A planer is used to smooth and level the flat surfaces of a board to a consistent thickness, while a jointer is used to create a square surface on the edge of a board. Jointers are also used to face joint one side which allows the planer to create parallel surfaces with uniform thickness. Planer and spindle moulders are widely used in furniture design, decoration, furniture production, doors and windows, cabinet manufacturing and other industries.

Wood Spindle Moulder Machine

Spindle Moulders can be used to cut much larger profiles than routers and custom made cutters can be readily ordered or fabricated. Spindle Moulders can be modified to perform specialised cuts

Add to Inquiry
Planer Woodworking Machine

Woodworking Tool Surface plane planer is used for planing the surface of wood, which is widely used in solid wood furniture. It is mainly composed of workbench, body, cutter shaft and driving device.

Add to Inquiry
Wood Planers Thicknesser

This 400 500 600mm width single side wood thicknesser planer is a high performance, high efficiency and low maintenance equipment, and it can help the factory improve processing efficiency while

Add to Inquiry
MB505 3KW woodworking planer

Woodworking Tool Surface plane planer is used for planing the surface of wood, which is widely used in solid wood furniture. It is mainly composed of workbench, body, cutter shaft and driving device.

Add to Inquiry
Planer four sided mold

The paper feeding system consists of the optimal number of drive rollers (located in and above the table). There are 4 drive rollers in the machine table. It is necessary to broach block workpieces

Add to Inquiry
Planer Thickening Machine

Woodworking 2 Sides Surface Thickness Planer is a two-sided machine to plane and mould timber on two sides in a single pass. this affordable and easy to use machine is designed for woodworkers who

Add to Inquiry
Single Side Wood Thicknesser

This 400 500 600mm width single side wood thicknesser planer is a high performance, high efficiency and low maintenance equipment, and it can help the factory improve processing efficiency while

Add to Inquiry
Solid Wood Moulder

Spindle Moulders can be used to cut much larger profiles than routers and custom made cutters can be readily ordered or fabricated. Spindle Moulders can be modified to perform specialised cuts

Add to Inquiry
45 degree molding machine

* The main shaft assembly adopts imported bearings and high-grade German grease to ensure the service life of the main shaft.. * After the main shaft assembly is rebalanced, the machine is more

Add to Inquiry

Why Choose Us

Rich Experience

OSETMAC has been focusing on the field of woodworking machinery for more than 8 years and is a recognized professional woodworking machinery manufacturer.

Professional Service

OSETMAC is able to do our own R&D, deliver production task on time and provide customer service quickly. Pay attention to changes in customer needs at any time and provide solutions in a timely manner.

Complete Qualifications

The manufacturing factories have already been granted ISO9001, and some of the main products have passed CE certificate.

Broad Market

Our products have been sold to more than 30 countries and regions in Middle East, Southeast Asia, Europe and South America.

Types of Planer and Spindle Moulder

MB505 3KW woodworking planer

MB505 3KW woodworking planer Jointer is mainly used by workbench tools such as flat planers for planing wood surfaces, with high productivity and suitable for large-scale production. Woodworking Tool Surface plane planer is used for planing the surface of wood, which is widely used in solid wood furniture. It is mainly composed of workbench, body, cutter shaft and driving device.

Wood Spindle Moulder Machine

Single spindle solid wood moulder spindle molds can be used to cut contours much larger than routers, and customized cutting tools can be easily ordered or manufactured. The spindle mold can be modified for specialized cutting by using various accessories such as sliding tables.

Specifications of Planer and Spindle Moulder

Model	MB-106BM
Max Working Width	630mm
Max Working Thickness	180mm
Min Working Thickness	3mm
Min Working Length	250mm
Max Cutting Capacity	≤4mm
Feeding Speed	6--8m/min
Spindle Speed	5500r/min
Motor Power	5.5kw
Machine Weight	550kg
Voltage	380V, 50Hz, 3 Phase
Dimension	76010601270mm

Features of Planer and Spindle Moulder

High work efficiency, low energy consumption, suitable for all kinds of wood products, economical and practical.

The machine structure design is reasonable, improve the safety, adapt to the emergency stop and treatment of various emergencies.

Usage Requirements of Planer and Spindle Moulder

1. Lathes contain several fast-rotating parts that can cause contact and entanglement hazards. Keep all body parts away from all rotating parts. Never wear loose-fitting clothing or jewelry while operating a lathe. Tie back and contain all long hair. Use guards to protect from accidental contact with rotating parts.

2. When the lathe spindle is set at too fast of an RPM, it will take longer for the spindle to stop rotating in an emergency situation. Limit spindle to 1000 RPM and use the lowest RPM applicable to the task.

3. Rotating and other moving parts can create pinch points. Pinch points can crush, bruise, lacerate, or amputate body parts. Utilize guards and avoid contact with these points.

4. Cutting Tools, drill bits, machined edges, chips, and cutoffs are potential cut and laceration hazards. Handle all sharp parts and tools with care. Do not clear chips with bare hands. Use a brush or compressed air (< 30psi).

5. There are several flying object hazards that can potentially come from a lathe. Make sure to secure both the workpiece and cutting tool. Be sure to remove the chuck key from the chuck. Make sure to keep the work area clean from all debris, chips, and tools.

6. High-speed metalworking can create burn hazards from the high amount of friction. Cutting chips, workpieces, and cutoffs can be hot to the touch during and immediately after the work process. Allow enough time for all objects to cool before handling them.

Certificate

Packaging and Delivery

Packaging	Wooden Cases, Cartons, Palletization.
Shipping	By logistics; by shipping; by air.
Payment	T/T, Paypal.

Our Services

Pre-sales Service

Understand customer requirements → Recommend appropriate products → Provide tailored solutions.

In-sales Service

Confirm order specifications → Monitor production progress → Address any changes in demand promptly → Deliver timely solutions.

After-sales Service

Gather customer feedback → Resolve issues efficiently and promptly.

FAQ

Q: What is the main difference between a planer and spindle moulder?

A: A planer is primarily used to flatten and smooth the surfaces of wood boards, creating a uniform thickness. It works by removing a small amount of material from the top surface of the wood. A spindle moulder, on the other hand, is used for shaping and profiling wood. It can create various decorative edges, grooves, and moldings by using different cutters and attachments.

Q: How do I maintain the blades of a planer and spindle moulder?

A: For both, keep the blades clean and free of debris. Regularly check for sharpness and replace or sharpen the blades when they become dull. Use appropriate blade - cleaning solutions and store the blades properly when not in use. For spindle moulder blades, make sure to store them in a way that protects the cutting edges from damage.

Q: What factors should I consider when choosing a planer?

A: Consider the width of the boards you will be processing (look for a planer with an appropriate table width), the maximum cutting depth, the power of the motor (especially if you'll be working with hard woods), and the type of feed system (e.g., manual or automatic). Also, check for features like adjustable outfeed tables and dust collection ports.

Q: How do I choose the right cutters for my spindle moulder?

A: Consider the shape and profile you want to create. There are many different types of cutters available, including straight cutters, rounded cutters, and decorative cutters. The diameter and thickness of the cutter should also be appropriate for your spindle moulder and the size of the workpiece.

Q: How do I adjust the cutting depth on a planer and spindle moulder?

A: On a planer, there is usually a depth - adjustment knob or lever that allows you to set the distance the cutting blades will remove from the wood surface. On a spindle moulder, the cutting depth is often adjusted by changing the height of the cutter relative to the workpiece. This may involve loosening and tightening bolts or using a calibrated adjustment mechanism.

As one of the most professional planer and spindle moulder manufacturers in China, we're featured by quality products and low price. Please rest assured to wholesale discount planer and spindle moulder from our factory. Contact us for customized service.
