Products Description
MJ6130TY Wood Cutting Machine
1. High quality cast iron machine table and aggregates
2. The right machine for every budget
3. Complete reliability in professional use
Desktop wood cutting machine is applied in various wood processing places, such as wood processing plants, home woodworking workshops, building material production plants, etc. Can be used for cutting and processing logs, as well as for trimming and polishing wood
Functional parameters
MJ6130TY Wood Cutting Machine
Cutting ability: refers to an important indicator of the performance of a wood cutting machine, expressed as the maximum cutting width and maximum cutting thickness. The cutting width refers to the maximum width that the cutting machine can cut, generally ranging from 200-600mm; The cutting thickness refers to the maximum processing thickness of wood by the cutting machine, generally ranging from 50-200mm
Scope of work: refers to the maximum working area that a wood cutting machine can handle For example, the working range of some thick wooden board laser cutting machines can reach 1300mm × 2500mm
Generally speaking, the motor power of MJ6130TY wood cutting machine between 3-7.5KW is more suitable for most users
Brief Introduce
> Manual rise/fall and tilt adjustment (0 – 45°)
The sliding table is constructed of anodized aluminum.
The core of aHigh Quality Wood Cutting Machine is the operation of the saw blade or circular saw blade. When the wood enters the working area of the cutting machine, the saw blade or circular saw blade begins to cut the wood downwards. After reaching the desired size, the saw blade or circular saw blade stops running, completing the cutting
High Quality Wood Cutting Machine Machines are under 12 months guarantee without man-made damage, during guarantee if parts refer to quality, High Quality Wood Cutting Machinecustomer can get new spare parts to replace broken components.
Specification
|
Sliding Table Dimension |
3000*375mm |
|
Cast Iron Table Dimension |
980*560*70mm |
|
Length Extension Table |
760*630*50mm |
|
Width Cutting Extension Table |
575*550*50mm |
|
Main Saw Diameter |
300mm |
|
Main Saw Blade Diameter Maximum |
315mm |
|
Main Saw Bore Diameter |
30mm |
|
Max. Cutting Height With Bade at 90 |
80/100mm(φ300/350) |
|
Max. Cutting Height With Bade at 45 |
55mm 50/70mm(φ300/350) |
|
Main Motor Power |
4KW(5.5KW) |
|
Main Blade Speed |
4000/6000RPM |
|
Scoring Saw Blade Diameter |
120mm |
|
Scoring Saw Bore Diameter |
20mm |
|
Scoring Saw Motor Power |
0.75KW(1.1KW) |
|
Scoring Blade Speed |
8000RPM |
|
Max. Cutting Width |
1250mm |
|
Max. Cutting Length |
3000mm |
|
Blade Tilting Adjustment |
0-45° |
|
Main Saw Height Adjustment |
Manual |
|
Scoring Saw Height Adjustment |
Manual |
|
Wood Packing Dimensions Main Crate and Sliding table |
2100*1100*1100mm 3400*420*220mm |
|
Installation Dimensions |
3250*3150*900mm |
|
Net Weight |
680KG |
